347V 25 Watt 120mA Emergency Battery Backup LED Driver

Product Categories
Ledsion Lighting LLC
Contact Now

347V 25 Watt 120mA Emergency Battery Backup LED Driver

Brand Name : LEDSION

Model Number : LSED25W

Certification : UL

Place of Origin : CHINA

MOQ : 100PC

Payment Terms : Western Union, MoneyGram, T/T, L/C

Supply Ability : 5000PC PER WEEK

Delivery Time : 24 HOURS

Packaging Details : 4PC PER CASE

Price : Negotiation

Product Name : LED Emergency Back Up Driver

Power : 25W

Rated input voltage : 100-277VAC,100-347VAC,50/60Hz

Recharge time : 24hours

Discharge time : 90 minutes

Warranty : 5 Years Warranty

Contact Now

US Stock LED Emergency Back Up Driver 90 Minutes Discharge For LED Tube Troffer Panel Flood Lights

Product description

  1. Suit for 10W to 300W lamp with internal or extemal led driver
  2. 10W-300W lamp must be with 0-10V dimmer function
  3. Used with Lifepo4 and Ni-cd battery
  4. DC150-200V output
  5. LED emergency converter that can transfer standard LED
  6. fitting into emergency LED fitting
  7. Accessary test switch and charge indicator

Applications

  • UL Listed for dry / damp locations
  • For use on a wide range of LED fittings to convert them from
  • standard to emergency fitting
  • Outout DC150-200V
  • Additional Relay that can control standard LED driver
  • Deep discharge protection
  • Ambient range ta 0 . 50C
  • IP20 protection
  • Not intended for use in luminaries for high-risk task area lighting
LSED suit for below lamp
25W above lamp must be with 0-10V or 1-10V dimmer.
Lamp power must be ≤24W(1W extra power) when dimmer is at the lowest voltage.
LED Product Name LED Emergency Lights
Rated input voltage
100-277VAC,100-347VAC,50/60Hz
Input current
120mA max
Warranty
5 Years Warranty
Power factor
0.6 @100VAC, 0.5@347VAC
Output wire L-out N-out
AC 6A Max
Output voltage range
AC120V,60Hz (sinusoid)
Max output voltage
250V
Recharge time
24hours
Discharge time
90 minutes

347V 25 Watt 120mA Emergency Battery Backup LED Driver347V 25 Watt 120mA Emergency Battery Backup LED Driver

347V 25 Watt 120mA Emergency Battery Backup LED Driver
